Wood SX350J and DNA mods I made

[CaptSteve]

I'm showing these just to inspire fellow vapers to get modding. I do not sell or make mods for sale



[Pdizzle]

Those are slick. Do you make your faceplates and do you use fdv battery tubes?



[CaptSteve]

I make everything myself, tubes and caps, buttons on a lathe and plates on a milling machine



[Spamby]

Well you better start selling them because I've just placed an order

Sent from my Nexus 6 using Tapatalk



[badinfluence357]

Just super capt!!!! Wow those are gorgeous capt..



[thomas l]

they're diffidently a work of art



[asdaq]

Great stuff Captain! Ranging from high end audio equipment to space gadgets, lovely styles.



[WharfRat1976]

Beautiful work. How about a few guts shots[emoji12]



[CaptSteve]

Thank you all for your kind words.

I'll post some progress pics throughout the build showing interiors prior to completion. If any of you also make mods please post I'd love to see your creations.



[Pdizzle]

@CaptSteve
I'm about to start a stabwood 26650 sx350j but I only have two battery caps, no tube. This is my first stabwood attempt and first time using these caps. I'm having the wood milled out by someone else as I'm lacking the tools. could you guide me in the right direction for a possible way of wiring this thing? Is it possible to do a sx350J on stabwood without desoldering the pre installed pos neg wires?



[Pdizzle]

This is what I'm working with
View image: FB IMG 1455296379158



[CaptSteve]

@CaptSteve
I'm about to start a stabwood 26650 sx350j but I only have two battery caps, no tube. This is my first stabwood attempt and first time using these caps. I'm having the wood milled out by someone else as I'm lacking the tools. could you guide me in the right direction for a possible way of wiring this thing? Is it possible to do a sx350J on stabwood without desoldering the pre installed pos neg wires?

Here's how to wire it with either single 18650 for a max of 60W or twin 18650's for 120W output. You will need to solder the wiring however



[CaptSteve]

This is what I'm working with
View image: FB IMG 1455296379158

Looks great, looking forward to see what you come up with.



[Pdizzle]

Thanks. I do know how to wire the sx350j as ive built a few. But I've never soldered to the battery caps before, I've only used keystones. I don't know how to get the inside battery contacts installed and then I'd assume since I don't have a tube I'd have to use my 510 as a ground?

Here's how to wire it with either single 18650 for a max of 60W or twin 18650's for 120W output. You will need to solder the wiring however



[CaptSteve]

You don't need a tube, you can bore out the stabilized wood to the depth required. make a brass disk as a positive contact and wire it to the BAT+ insert the battery and then the end cap you have and solder to the end cap the BAT- as the diagram.
You can epoxy the end cap tube in so when you screw the cap it's flush with the bottom of the mod

Easiest way and cuts down on weight



[Pdizzle]

Thanks I'll try that



[CaptSteve]

I did exactly that with this mod



[Steamer861]

Simply Stunning! It is so nice to see a mod that looks like Art Work, That is not just a plain Mec mod.
Gorgeous Wood state of the art regulated chips. Hats off to you CaptSteve You have takin it to the next level



[Pdizzle]

You just epoxy your faceplates in? No screws eh?



[CaptSteve]

Yep, epoxy is all you need
